Description
| Model | CAH-320 | CAH-450 | CAH-630 | ||
| Cooling capacity | W | 320 | 450 | 630 | |
| Btu/Hr | 1092 | 1536 | 2150 | ||
| Cabinet temperature range | ℃ | 15-45 | |||
| Ambient temperature range | ℃ | 15-55 | |||
| System Max. pressure | bar | 26 | |||
| Power source | V/ph/Hz | 220/1/50 | |||
| Rated current | A | 1.2 | 1.4 | 1.6 | |
| Input power | W | 245 | 290 | 350 | |
| Air volume inside | m³ /h | 165 | 240 | 320 | |
| Air volume outside | m³ /h | 325 | 450 | 575 | |
| Refrigerant | R134a | ||||
| Internal IP level | IP54 | ||||
| External IP level | IP30 | ||||
| Noise | dB(A) | 55 | 56 | 58 | |
| Weight | kg | 14 | 18 | 22 | |
| Dimension | High | mm | 290 | ||
| Width | mm | 520 | |||
| Deep | mm | 220 | |||
Support customization
Technological innovationWe never stop innovating…
-
Stainless steel shell and tube evaporator -
Innovative V-shaped fin condenser
-
Innovative new cylindrical water tank
-
High efficiency and low noise fan
-
Intelligent touch screen controller
-
High precision controller
Powerful energy savingVery power-saving!
-
Copper tube with internal thread
-
Sinusoidal heat transfer fins
-
Electric expansion PID technology
-
Innovative refrigerant distribution technology
-
Professional air flow channel design
-
Air volume automatic control
Multiple protection
-
Condensed water evaporation
-
Compressor protection
-
Dehumidification optional
-
Heating optional
-
Over temperature protection
-
Water level alarm
-
Pressure alarm
-
Effective filtration
Quality controlEvery detail, we are meticulous …
-
Famous brand compressor
-
Imported brand accessories
-
Keep improving everywhere
-
3D pipe bending machine
-
Automatic refrigerant adding machine
-
Automatic welding machine
Precision technologyPrecision technology makes products better
-
Sheet metal precision drawing
-
Drawing forming guide ring
-
Robot bending machine
-
Laser welding
-
Automatic cutting machine
-
Automatic joint welding
