Description
Specifications
| Model
ltem |
ICA-2U | ICA-3U | ICA-5U | ICA-8U | ICA-10U | ICA-12U | ||
| Performance parameter | ||||||||
| Cooling capacity | kW | 1.2 | 1.6 | 4.8 | 6.3 | 7.3 | 8.9 | |
| 10³kcal/h | 1.03 | 1.4 | 4.1 | 5.4 | 6.3 | 7.7 | ||
| Power source | V/ph/Hz | 380/3/50 | ||||||
| Power input | kW | 2.2 | 2.7 | 4.2 | 5.7 | 7.2 | 8.7 | |
| Current | A | 4.9 | 6.0 | 9.3 | 12.5 | 15.2 | 17.5 | |
| Main component | ||||||||
| Compressor | Type | Scroll | ||||||
| Power | kW | 1.2 | 1.7 | 3.0 | 4.1 | 4.9 | 5.5 | |
|
Pump |
Head | m | 42 | 44 | 41 | 45 | 42 | 40 |
| Power | kW | 0.75 | 0.75 | 0.75 | 1.3 | 1.3 | 2.2 | |
| Flow | m³/h | 0.21 | 0.28 | 0.79 | 1.08 | 1.26 | 1.53 | |
| L/min | 3.4 | 4.6 | 13.2 | 18.0 | 21.0 | 25.5 | ||
| Tank capacity | L | 40 | 50 | 70 | 100 | 155 | 155 | |
| Pipe size | DN | 20 | 25 | 40 | ||||
| Noise/Weight/Dimension | ||||||||
| Noise | dB(A) | 62 | 63 | 65 | 68 | 68 | 69 | |
| Weight | kg | 110 | 162 | 188 | 210 | 260 | 310 | |
|
Dim. |
L | mm | 600 | 680 | 750 | 1350 | 1510 | 1510 |
| W | mm | 600 | 680 | 750 | 680 | 750 | 750 | |
| H | mm | 1160 | 1360 | 1480 | 1360 | 1480 | 1480 | |
| Model
Item |
ICA-15U | ICA-20U | ICA-25U | ICA-30U | ICA-40U | ICA-50U | ||
| Performance parameter | ||||||||
| Cooling capacity | kW | 10.9 | 15.0 | 17.8 | 21.8 | 30.0 | 35.6 | |
| 10³kcal/h | 9.4 | 12.9 | 15.3 | 18.7 | 25.8 | 30.6 | ||
| Power source | V/ph/Hz | 380/3/50 | ||||||
| Power input | kW | 10.2 | 15.3 | 16.5 | 20.0 | 26.6 | 30.0 | |
| Current | A | 22.5 | 33.7 | 36.3 | 45.0 | 58.5 | 66.0 | |
| Main component | ||||||||
| Compressor | Scroll | |||||||
| Power | kW | 6.7 | 9.8 | 11.0 | 13.4 | 19.6 | 22.0 | |
|
Pump |
Head | m | 40 | 42 | 41 | 45 | 42 | 40 |
| Power | kW | 2.2 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | |
| Flow | m³/h | 1.88 | 2.58 | 3.06 | 3.75 | 5.16 | 6.12 | |
| L/min | 31.3 | 43.0 | 51.0 | 62.5 | 86.0 | 102.0 | ||
| Tank capacity | L | 155 | 230 | 230 | 230 | 300 | 300 | |
| Pipe size | DN | 40 | 50 | |||||
| Noise/Weight/Dimension | ||||||||
| Noise | dB(A) | 69 | 68 | 68 | 68 | 69 | 69 | |
| Weight | kg | 415 | 620 | 670 | 780 | 1100 | 1300 | |
|
Dim. |
L | mm | 1785 | 2080 | 2080 | 2080 | 2200 | 3000 |
| W | mm | 915 | 1050 | 1050 | 1050 | 1200 | 1200 | |
| H | mm | 1630 | 1720 | 1720 | 1910 | 2135 | 2120 | |
*With the technological progress,we will periodically update products.Please follow KANSA website
Technological innovationWe never stop innovating…
-
Stainless steel shell and tube evaporator -
I nnovative V-shaped fin condenser
-
Innovative new cylindrical water tank
-
High efficiency and low noise fan
-
Intelligent touch screen controller
-
High precision controller
Powerful energy savingVery power-saving!
-
Copper tube with internal thread
-
Sinusoidal heat transfer fins
-
Electric expansion PID technology
-
Innovative refrigerant distribution technology
-
Professional air flow channel design
-
Air volume automatic control
Multiple protection
-
Over temperature protection
-
Current protection
-
Self-diagnosis
-
Intelligent antifreeze
-
Water flow alarm
-
Water level alarm
-
Pressure alarm
-
Timing switch on and off
Quality controlEvery detail, we are meticulous …
-
Famous brand compressor
-
Imported brand accessories
-
Keep improving everywhere
-
3D pipe bending machine
-
Automatic refrigerant adding machine
-
Automatic welding machine
Precision technologyPrecision technology makes products better
-
Sheet metal precision drawing
-
Drawing forming guide ring
-
Robot bending machine
-
Laser welding
-
Automatic cutting machine
-
Automatic joint welding
