Description
| Item / Model | NEC-2A NEC-2W |
NEC-3A NEC-3W |
NEC-5A NEC-5W |
NEC-6A NEC-6W |
|
| Cooling capacity kW | 0℃ Liquid temperature | 3.5 | 5.5 | 9.0 | 10.5 |
| 20℃ Liquid temperature | 6.0 | 9.0 | 15.0 | 18.0 | |
| Flow | Flow range | 2-15 L/min | 2-20 L/min | 3-30 L/min | 4-40 L/min |
| Flow accuracy | ±0.2 L/Min | ||||
| Output groups | Single/dual/triple optional | ||||
| Temperature | Range | 0~100℃ | |||
| Accuracy | ±0.1/±0.2℃ | ||||
| Detection | PT100 | ||||
| Pressure | Display/Control | Pressure display/pressure controlled selectively | |||
| Pressure range | 2~3bar | ||||
| Communication | Interface type | Modbus rtu protocol, rs485 interface, optional can communication bus, ethernet interface tcp/ip protocol | |||
| Power source | V/ph/Hz | 380/3/50（Non-standard power supply can be customized） | |||
| Compressor | Type | Imported brand flexible scroll compressor | |||
| Pump | Type | Stainless steel multistage variable frequency water pump | |||
| Evaporator | Type | Stainless steel coil type/stainless steel shell and tube type | |||
| Condenser | Air cooled type | Hydrophilic aluminum foil + internal thread copper pipe | |||
| Water cooled type | Shell and tube type | ||||
| Throttle element | Expansion valve | ||||
| Control panel | 7-inch touch screen | ||||
| Safety protection | Pressure, current, cemperature, flow, liquid level, power supply, etc | ||||
| Water pipe size | G-3/4” | ||||
| Refrigerant | R410A/R407C | ||||
| Item / Model | NEC-8A NEC-8W |
NEC-10A NEC-10W |
NEC-12A NEC-12W |
NEC-15A NEC-15W |
|
| Cooling capacity kW | 0℃ Liquid temperature | 14.5 | 14.5 | 22.0 | 27.0 |
| 20℃ Liquid temperature | 24.0 | 30.0 | 36.0 | 45.0 | |
| Flow | Flow range | 4-40L/min | 4-40L/min | 5-50L/min | 5-50L/min |
| Flow accuracy | ±0.2 L/Min | ||||
| Output groups | Single/dual/triple optional | ||||
| Temperature | Range | 0~100℃ | |||
| Accuracy | ±0.1/±0.2℃ | ||||
| Detection | PT100 | ||||
| Pressure | Display/Control | Pressure display/pressure controlled selectively | |||
| Pressure range | 2~3bar | ||||
| Communication | Interface type | Modbus rtu protocol, rs485 interface, optional can communication bus, ethernet interface tcp/ip protocol | |||
| Power source | V/ph/Hz | 380/3/50（Non-standard power supply can be customized） | |||
| Compressor | Type | Imported brand flexible scroll compressor | |||
| Pump | Type | Stainless steel multistage variable frequency water pump | |||
| Evaporator | Type | Stainless steel coil type/stainless steel shell and tube type | |||
| Condenser | Air cooled type | Hydrophilic aluminum foil + internal thread copper pipe | |||
| Water cooled type | Shell and tube type | ||||
| Throttle element | Expansion valve | ||||
| Control panel | 7-inch touch screen | ||||
| Safety protection | Pressure, current, cemperature, flow, liquid level, power supply, etc | ||||
| Water pipe size | G-3/4” | ||||
| Refrigerant | R410A/R407C | ||||
Technological innovationWe never stop innovating…
-
Stainless steel shell and tube evaporator -
I nnovative V-shaped fin condenser
-
Innovative new cylindrical water tank
-
High efficiency and low noise fan
-
Intelligent touch screen controller
-
High precision controller
Powerful energy savingVery power-saving!
-
Copper tube with internal thread
-
Sinusoidal heat transfer fins
-
Electric expansion PID technology
-
Innovative refrigerant distribution technology
-
Professional air flow channel design
-
Air volume automatic control
Multiple protection
-
Over temperature protection
-
Current protection
-
Self-diagnosis
-
Intelligent antifreeze
-
Water flow alarm
-
Water level alarm
-
Pressure alarm
-
Timing switch on and off
Quality controlEvery detail, we are meticulous …
-
Famous brand compressor
-
Imported brand accessories
-
Keep improving everywhere
-
3D pipe bending machine
-
Automatic refrigerant adding machine
-
Automatic welding machine
Precision technologyPrecision technology makes products better
-
Sheet metal precision drawing
-
Drawing forming guide ring
-
Robot bending machine
-
Laser welding
-
Automatic cutting machine
-
Automatic joint welding
