Description
| Item / Model | ICQ-0.6J | ICQ-1J | ICQ-1.5J | ICQ-2J | ICQ-3J | ||
| Cooling capacity | kW | 0.6 | 2.7 | 3.5 | 5.2 | 9.0 | |
| Total power input | kW | 0.8 | 1.1 | 1.5 | 2.2 | 3.1 | |
| Power source | V/ph/Hz | 220V/1/50 | 380V/3/50Hz | ||||
| Rated current | A | 3.8 | 6.6 | 8.2 | 10.0 | 7.0 | |
| Compressor | Type | Rotor type | |||||
| Power | kW | 0.5 | 0.8 | 1.2 | 1.6 | 2.3 | |
| Condenser | Type | High efficiency internal thread copper pipe fin type | |||||
| Evaporator | Type | Water tank coil type | |||||
| Noise | dB(A) | 56 | 58 | 59 | 60 | 61 | |
| Weight | kg | 40 | 55 | 75 | 95 | 120 | |
| Dimension | Lenth | mm | 450 | 500 | 500 | 600 | 680 |
| Width | mm | 450 | 500 | 500 | 600 | 680 | |
| High | mm | 1400 | 1125 | 1125 | 1120 | 1340 | |
| Item / Model | ICQ-5J | ICQ-6J | ICQ-8J | ICQ-10J | ICQ-12J | ||
| Cooling capacity | kW | 15.0 | 18.0 | 23.0 | 29.5 | 35.0 | |
| Total power input | kW | 5.2 | 5.9 | 7.9 | 9.8 | 11.0 | |
| Power source | V/ph/Hz | 380V/3/50Hz | |||||
| Rated current | A | 3.8 | 6.6 | 8.2 | 10.0 | 7.0 | |
| Compressor | Type | Flexible scroll type | |||||
| Power | kW | 4.2 | 5.1 | 6.9 | 8.7 | 10.1 | |
| Condenser | Type | High efficiency internal thread copper pipe fin type | |||||
| Evaporator | Type | Water tank coil type | |||||
| Noise | dB(A) | 62 | 63 | 64 | 66 | 68 | |
| Weight | kg | 150 | 170 | 210 | 260 | 290 | |
| Dimension | Lenth | mm | 750 | 750 | 1000 | 1000 | 1000 |
| Width | mm | 750 | 750 | 1000 | 1000 | 1000 | |
| High | mm | 1790 | 1990 | 1935 | 1935 | 1935 | |
Support customization
Technological innovationWe never stop innovating…
Stainless steel shell and tube evaporator
Innovative V-shaped fin condenser
Innovative new cylindrical water tank
High efficiency and low noise fan
Intelligent touch screen controller
High precision controller
Powerful energy savingVery power-saving!
Copper tube with internal thread
Sinusoidal heat transfer fins
Electric expansion PID technology
Innovative refrigerant distribution technology
Professional air flow channel design
Air volume automatic control
Multiple protection
Over temperature protection
Current protection
Self-diagnosis
Intelligent antifreeze
Water flow alarm
Water level alarm
Pressure alarm
Timing switch on and off
Quality controlEvery detail, we are meticulous …
Famous brand compressor
Imported brand accessories
Keep improving everywhere
3D pipe bender
Automatic refrigerant adding machine
Automatic welding machine
Precision technologyPrecision technology makes products better
Sheet metal precision drawing
Drawing forming guide ring
Robot bending machine
Laser welding
Automatic cutting machine
Automatic joint welding
